| 型号 | 物方视场(mm) | 光学倍率 | 工作距离(mm) | F.NO | 远心度 | 畸变(%) | 分辨率(um) | 景深(mm) | 接口 | 芯片 | 文件预览 | 查看详情 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BTL0.182X410B44 | 241.8 | 0.182 | 410±5 | 6 | <0.1° | <0.1 | 34.34 | 14 | M58 | 44 | 详情 | |
| BTL0.257X318B44 | 171.2 | 0.257 | 318±4 | 6 | <0.1° | <0.1 | 24.31 | 6 | M58 | 44 | 详情 | |
| BTL0.292X301B44 | 150.7 | 0.292 | 301±4 | 10 | <0.1° | <0.1 | 21.4 | 12 | M58 | 44 | 详情 | |
| BTL0.321X288B44 | 137.1 | 0.321 | 288±4 | 6.2 | <0.1° | <0.1 | 18.32 | 4 | M58 | 44 | 详情 | |
| BTL0.392X251B44 | 112.2 | 0.392 | 251±3 | 8 | <0.1° | <0.1 | 19.62 | 6 | M58 | 44 | 详情 | |
| BTL0.439X238B44 | 100.2 | 0.439 | 238±3 | 10.2 | <0.1° | <0.1 | 16.99 | 5 | M58 | 44 | 详情 | |
| BTL0.486X208B44 | 90.5 | 0.486 | 208±2 | 11.4 | <0.1° | <0.1 | 12.86 | 4 | M58 | 44 | 详情 | |
| BTL0.547X230B44 | 76.7 | 0.574 | 230±2 | 12.8 | <0.1° | <0.1 | 11.71 | 5 | M58 | 44 | 详情 | |
| BTL0.608X178B44 | 72.4 | 0.608 | 178±2 | 10.3 | <0.1° | <0.1 | 10.15 | 2.4 | M58 | 44 | 详情 | |
| BTL0.680X187B44 | 64.7 | 0.68 | 187±2 | 20.5 | <0.1° | <0.1 | 11.48 | 7 | M58 | 44 | 详情 | |
| BTL0.682X159B44 | 64.5 | 0.682 | 159±2 | 10 | <0.1° | <0.1 | 9.77 | 3 | M58 | 44 | 详情 | |
| BTL0.782X138B44 | 56.3 | 0.782 | 138±2 | 12 | <0.1° | <0.1 | 7.99 | 2 | M58 | 44 | 详情 | |
| BTL0.911X128B44 | 44.4 | 0.991 | 128±2 | 17.1 | <0.1° | <0.1 | 7.2 | 2 | M58 | 44 | 详情 | |
| BTL1.048X118A44 | 42.0 | 1.048 | 118 | 17.2 | <0.1° | <0.1 | 9.54 | 1.4 | M58 | 44 | 详情 | |
| BTL1.212X111B44 | 36.3 | 1.212 | 111±2 | 18.7 | <0.1° | <0.1 | 6.25 | 1.2 | M58 | 44 | 详情 | |
| BTL1.685X72B44 | 26.1 | 1.685 | 72±2 | 22.8 | <0.1° | <0.1 | 5.81 | 1.2 | M58 | 44 | 详情 |
