| 型号 | 物方视场(mm) | 光学倍率 | 工作距离(mm) | F.NO | 远心度 | 畸变(%) | 分辨率(um) | 景深(mm) | 接口 | 芯片 | 文件预览 | 查看详情 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BTL0.163X410B39 | 231.9 | 0.163 | 410 | 6.5 | <0.1° | <0.1 | 38.34 | 20 | M58 | 39 | 详情 | |
| BTL0.230X318B39 | 164.3 | 0.23 | 318 | 6.5 | <0.1° | <0.1 | 25.57 | 11 | M58 | 39 | 详情 | |
| BTL0.261X301B39 | 144.8 | 0.261 | 301 | 10 | <0.1° | <0.1 | 22.53 | 10 | M58 | 39 | 详情 | |
| BTL0.287X288B39 | 131.7 | 0.287 | 288 | 7 | <0.1° | <0.1 | 21.77 | 9 | M58 | 39 | 详情 | |
| BTL0.351X251B39 | 107.7 | 0.351 | 251 | 8.5 | <0.1° | <0.1 | 17.8 | 6 | M58 | 39 | 详情 | |
| BTL0.393X238B39 | 96.2 | 0.393 | 238 | 9.1 | <0.1° | <0.1 | 16.31 | 5 | M58 | 39 | 详情 | |
| BTL0.434X208B39 | 87.1 | 0.434 | 208 | 10.2 | <0.1° | <0.1 | 13.88 | 4 | M58 | 39 | 详情 | |
| BTL0.488X230B39 | 77.5 | 0.488 | 230 | 11.5 | <0.1° | <0.1 | 14.23 | 5 | M58 | 39 | 详情 | |
| BTL0.543X178B39 | 69.6 | 0.543 | 178 | 10.5 | <0.1° | <0.1 | 13.15 | 4 | M58 | 39 | 详情 | |
| BTL0.610X159B39 | 62.0 | 0.61 | 159 | 10 | <0.1° | <0.1 | 11.7 | 3 | M58 | 39 | 详情 | |
| BTL0.613X187B39 | 61.7 | 0.613 | 187±2 | 18 | <0.1° | <0.1 | 4.36 | 7 | M58 | 39 | 详情 | |
| BTL0.698X138B39 | 54.2 | 0.698 | 138 | 10 | <0.1° | <0.1 | 8.95 | 2 | M58 | 39 | 详情 | |
| BTL0.814X128B39 | 46.4 | 0.814 | 128 | 15 | <0.1° | <0.1 | 8.77 | 2 | M58 | 39 | 详情 | |
| BTL0.931X118B39 | 40.6 | 0.931 | 118 | 15.3 | <0.1° | <0.1 | 8.26 | 2 | M58 | 39 | 详情 | |
| BTL1.080X111B39 | 35.0 | 1.08 | 111 | 18 | <0.1° | <0.1 | 7.12 | 2 | M58 | 39 | 详情 | |
| BTL1.503X72B39 | 25.2 | 1.5 | 72 | 20.4 | <0.1° | <0.1 | 6.06 | 2 | M58 | 39 | 详情 |
