| 型号 | 物方视场(mm) | 光学倍率 | 工作距离(mm) | F.NO | 远心度 | 畸变(%) | 分辨率(um) | 景深(mm) | 接口 | 芯片 | 文件预览 | 查看详情 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BTL0.069X410B1 | 231.9 | 0.069 | 410 | 6 | <0.1° | <0.1 | 42.87 | 52 | C | 1 | 详情 | |
| BTL0.098X318B1 | 163.3 | 0.098 | 318 | 6 | <0.1° | <0.1 | 30.36 | 26 | C | 1 | 详情 | |
| BTL0.111X301B1 | 144.1 | 0.111 | 301 | 6.5 | <0.1° | <0.1 | 27.13 | 30 | C | 1 | 详情 | |
| BTL0.122X288B1 | 131.1 | 0.122 | 288 | 6 | <0.1° | <0.1 | 24.99 | 18 | C | 1 | 详情 | |
| BTL0.149X251B1 | 107.4 | 0.149 | 251 | 6 | <0.1° | <0.1 | 20.21 | 14 | C | 1 | 详情 | |
| BTL0.168X238B1 | 95.2 | 0.168 | 238 | 6.5 | <0.1° | <0.1 | 18.14 | 16 | C | 1 | 详情 | |
| BTL0.185X208B1 | 86.5 | 0.185 | 208 | 6.5 | <0.1° | <0.1 | 16.38 | 10 | C | 1 | 详情 | |
| BTL0.208X230B1 | 76.9 | 0.208 | 230 | 6.5 | <0.1° | <0.1 | 14.856 | 8 | C | 1 | 详情 | |
| BTL0.232X178B1 | 69.0 | 0.232 | 178 | 6 | <0.1° | <0.1 | 12.67 | 6 | C | 1 | 详情 | |
| BTL0.259X159B1 | 61.8 | 0.259 | 159 | 6 | <0.1° | <0.1 | 11.55 | 5 | C | 1 | 详情 | |
| BTL0.260X187B1 | 61.5 | 0.26 | 187 | 7.8 | <0.1° | <0.1 | 12.56 | 8 | C | 1 | 详情 | |
| BTL0.298X138B1 | 53.7 | 0.298 | 138 | 5.6 | <0.1° | <0.1 | 10.16 | 3 | C | 1 | 详情 | |
| BTL0.347X128B1 | 46.1 | 0.347 | 128 | 8 | <0.1° | <0.1 | 9.67 | 5 | C | 1 | 详情 | |
| BTL0.398X118B1 | 40.2 | 0.398 | 118 | 6.5 | <0.1° | <0.1 | 8.78 | 2 | C | 1 | 详情 | |
| BTL0.461X111B1 | 34.7 | 0.461 | 111 | 7.8 | <0.1° | <0.1 | 7.91 | 2 | C | 1 | 详情 | |
| BTL0.642X72B1 | 24.9 | 0.642 | 72 | 9 | <0.1° | <0.1 | 8.58 | 1.2 | C | 1 | 详情 | |
| TL0.7X107A1 | 22.9 | 0.7 | 107.2 | 7 | <0.1° | <0.05 | 5.3 | 0.64 | C | 1 | 详情 | |
| TC0.7X107A1 | 22.9 | 0.7 | 107.2 | 7 | <0.1° | <0.05 | 5.3 | 0.64 | C | 1 | 详情 | |
| TC5X65A1 | 3.2 | 5 | 62.5 | ＞13.8 | <0.15° | <0.05 | 1.56 | C | 1 | 详情 |
