| 型号 | 物方视场(mm) | 光学倍率 | 工作距离(mm) | F.NO | 远心度 | 畸变(%) | 分辨率(um) | 景深(mm) | 接口 | 芯片 | 文件预览 | 查看详情 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BTL0.030X410B125 | 237 | 0.03 | 410±5 | F4 | <0.1° | <0.1 | 90 | 72 | C | 1/2.5 | 详情 | |
| BTL0.042X318B125 | 169 | 0.042 | 318±4 | F4.2 | <0.1° | <0.1 | 64 | 54 | C | 1/2.5 | 详情 | |
| BTL0.048X301B125 | 148 | 0.048 | 301±4 | F5 | <0.1° | <0.1 | 54 | 44 | C | 1/2.5 | 详情 | |
| BTL0.053X288B125 | 134 | 0.053 | 288±4 | F3.8 | <0.1° | <0.1 | 49 | 34 | C | 1/2.5 | 详情 | |
| BTL0.065X251B125 | 109 | 0.065 | 251±3 | F.4 | <0.1° | <0.1 | 41 | 22 | C | 1/2.5 | 详情 | |
| BTL0.072X238B125 | 98 | 0.072 | 238±3 | F4.2 | <0.1° | <0.1 | 36 | 20 | C | 1/2.5 | 详情 | |
| BTL0.080X208B125 | 89 | 0.08 | 208±2 | F4.2 | <0.1° | <0.1 | 33 | 18 | C | 1/2.5 | 详情 | |
| BTL0.090X230B125 | 79 | 0.09 | 230±2 | F4.2 | <0.1° | <0.1 | 31 | 10 | C | 1/2.5 | 详情 | |
| BTL0.100X178B125 | 71 | 0.1 | 178±2 | F4.2 | <0.1° | <0.1 | 27 | 16 | C | 1/2.5 | 详情 | |
| BTL0.112X159B125 | 63 | 0.112 | 159±2 | F4.2 | <0.1° | <0.1 | 24 | 12 | C | 1/2.5 | 详情 | |
| BTL0.113X187B125 | 63 | 0.113 | 187±2 | F4.2 | <0.1° | <0.1 | 23 | 12 | C | 1/2.5 | 详情 | |
| BTL0.129X138B125 | 55 | 0.129 | 138±2 | F4.5 | <0.1° | <0.1 | 19 | 8 | C | 1/2.5 | 详情 | |
| BTL0.150X128B125 | 47 | 0.15 | 128±2 | F4.5 | <0.1° | <0.1 | 17 | 6 | C | 1/2.5 | 详情 | |
| BTL0.172X118B125 | 41 | 0.172 | 118±2 | F4.2 | <0.1° | <0.1 | 15 | 5 | C | 1/2.5 | 详情 | |
| BTL0.199X111B125 | 35 | 0.199 | 111±2 | F4.5 | <0.1° | <0.1 | 14 | 4 | C | 1/2.5 | 详情 | |
| BTL0.277X72B125 | 29 | 0.277 | 72±2 | F3 | <0.1° | <0.1 | 10 | 6 | C | 1/2.5 | 详情 |
