| 型号 | 物方视场(mm) | 光学倍率 | 工作距离(mm) | F.NO | 远心度 | 畸变(%) | 分辨率(um) | 景深(mm) | 接口 | 芯片 | 文件预览 | 查看详情 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BTL0.037X410B118 | 243.2 | 0.037 | 410±5 | 4.2 | <0.1° | <0.1 | 72.6 | 70 | C | 1/1.8 | 详情 | |
| BTL0.053X318B118 | 169.8 | 0.053 | 308±4 | 4.2 | <0.1° | <0.1 | 50.1 | 48 | C | 1/1.8 | 详情 | |
| BTL0.060X301B118 | 150.0 | 0.06 | 301±4 | 4.2 | <0.1° | <0.1 | 44.3 | 38 | C | 1/1.8 | 详情 | |
| BTL0.066X288B118 | 136.4 | 0.066 | 288±4 | 4.2 | <0.1° | <0.1 | 40.7 | 32 | C | 1/1.8 | 详情 | |
| BTL0.081X251B118 | 111.1 | 0.081 | 251±3 | 4.2 | <0.1° | <0.1 | 34.1 | 24 | C | 1/1.8 | 详情 | |
| BTL0.091X238B118 | 98.9 | 0.091 | 238±3 | 4.7 | <0.1° | <0.1 | 29.8 | 22 | C | 1/1.8 | 详情 | |
| BTL0.100X208B118 | 90.0 | 0.1 | 208±2 | 4.7 | <0.1° | <0.1 | 26.3 | 16 | C | 1/1.8 | 详情 | |
| BTL0.113X230B118 | 79.6 | 0.113 | 230±2 | 4.7 | <0.1° | <0.1 | 22.9 | 14 | C | 1/1.8 | 详情 | |
| BTL0.125X178B118 | 72.0 | 0.125 | 178±2 | 4.7 | <0.1° | <0.1 | 20.9 | 12 | C | 1/1.8 | 详情 | |
| BTL0.140X159B118 | 64.3 | 0.14 | 159±2 | 4.2 | <0.1° | <0.1 | 19.5 | 10 | C | 1/1.8 | 详情 | |
| BTL0.141X187B118 | 63.8 | 0.141 | 187±2 | 5.3 | <0.1° | <0.1 | 19.3 | 10 | C | 1/1.8 | 详情 | |
| BTL0.161X138B118 | 55.9 | 0.161 | 138±2 | 4.7 | <0.1° | <0.1 | 16.17 | 7 | C | 1/1.8 | 详情 | |
| BTL0.187X128B118 | 48.1 | 0.187 | 128±2 | 5.3 | <0.1° | <0.1 | 14.8 | 6 | C | 1/1.8 | 详情 | |
| BTL0.215X118B118 | 41.9 | 0.215 | 118±2 | 4.7 | <0.1° | <0.1 | 13.2 | 5 | C | 1/1.8 | 详情 | |
| BTL0.250X111B118 | 36.0 | 0.25 | 111±2 | 5.3 | <0.1° | <0.1 | 10.6 | 4 | C | 1/1.8 | 详情 | |
| BTL0.347X72B118 | 25.9 | 0.347 | 72±2 | 5.3 | <0.1° | <0.1 | 8.65 | 2.4 | C | 1/1.8 | 详情 | |
| BTL0.5X200A118 | 18.0 | 0.5 | 197.1±3 | / | <0.1° | <0.03 | 8.33 | 10 | C | 1/1.8 | 详情 | |
| TL0.5X65A118 | 18.0 | 0.5 | 65 | 7.5 | <0.1° | <0.05 | 7.5 | 1.2 | C | 1/1.8 | 详情 | |
| TL0.5X200A118 | 18.0 | 0.5 | 197±3 | 8 | <0.1° | <0.03 | 8.3 | 1.4 | C | 1/1.8 | 详情 | |
| TC0.5X65A118 | 18.0 | 0.5 | 65 | 7.5 | <0.1° | <0.05 | 7.5 | 1.2 | C | 1/1.8 | 详情 |
