| 型号 | 物方视场(mm) | 光学倍率 | 工作距离(mm) | F.NO | 远心度 | 畸变(%) | 分辨率(um) | 景深(mm) | 接口 | 芯片 | 文件预览 | 查看详情 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BTL0.137X410B2 | 240.9 | 0.137 | 410±5 | 6.5 | <0.1° | <0.1 | 46.19 | 20 | M58 | 2 | 详情 | |
| BTL0.194X318B2 | 170.1 | 0.194 | 318±4 | 7.8 | <0.1° | <0.1 | 31.81 | 14 | M58 | 2 | 详情 | |
| BTL0.220X301B2 | 150.0 | 0.22 | 301±4 | 7.8 | <0.1° | <0.1 | 29.51 | 12 | M58 | 2 | 详情 | |
| BTL0.242X288B2 | 136.4 | 0.242 | 288±4 | 7.8 | <0.1° | <0.1 | 25.82 | 9 | M58 | 2 | 详情 | |
| BTL0.296X251B2 | 111.5 | 0.296 | 251±3 | 7.8 | <0.1° | <0.1 | 22.22 | 8 | M58 | 2 | 详情 | |
| BTL0.332X238B2 | 99.4 | 0.332 | 238±3 | 7.7 | <0.1° | <0.1 | 19.55 | 5 | M58 | 2 | 详情 | |
| BTL0.367X208B2 | 89.9 | 0.367 | 230±2 | 8.6 | <0.1° | <0.1 | 18.16 | 5 | M58 | 2 | 详情 | |
| BTL0.412X230B2 | 80.1 | 0.412 | 230±2 | 9.7 | <0.1° | <0.1 | 16.18 | 4 | M58 | 2 | 详情 | |
| BTL0.458X178B2 | 72.1 | 0.458 | 178±2 | 7.8 | <0.1° | <0.1 | 14.17 | 3 | M58 | 2 | 详情 | |
| BTL0.514X159B2 | 64.2 | 0.514 | 159±2 | 9.7 | <0.1° | <0.1 | 12.79 | 3 | M58 | 2 | 详情 | |
| BTL0.515X187B2 | 64.1 | 0.515 | 187±2 | 12.9 | <0.1° | <0.1 | 14.49 | 5 | M58 | 2 | 详情 | |
| BTL0.589X138B2 | 56.0 | 0.589 | 138±2 | 9.7 | <0.1° | <0.1 | 11.16 | 3 | M58 | 2 | 详情 | |
| BTL0.685X128B2 | 48.2 | 0.685 | 128±2 | 12.9 | <0.1° | <0.1 | 10.28 | 3 | M58 | 2 | 详情 | |
| BTL0.786X118B | 42.0 | 0.786 | 118±2 | 12.9 | <0.1° | <0.1 | 9.35 | 2 | M58 | 2 | 详情 | |
| BTL0.914X111B2 | 36.1 | 0.914 | 111±2 | 17.2 | <0.1° | <0.1 | 8.68 | 2 | M58 | 2 | 详情 | |
| BTL1.272X72B2 | 25.9 | 1.272 | 72±2 | 17.2 | <0.1° | <0.1 | 6.34 | 1.6 | M58 | 2 | 详情 |
